HL 1000 ton 4 column press

Producto agregado a sus favoritos

» Solicitar un presupuesto personalizado

Información téchnico

Capacity1000 ton
Passage between uprights1000 mm
Max ram adjustment800 mm
Distance between table -- ram1400 mm
Table area1200 x 1000 mm
Electric motor (power)55 kW
Length L -- R1200 mm
Depth Fw -- Bw1200 mm
Height5500 mm
Weight25 ton

Información adicional

4 column hydraulic press
high closing speed
ideal for composite projects
press can remain under pressure for a long period of time
one main hydraulic single acting piston (diameter 660 mm)
two smaller pistons to retract the stamp
heating can used as an option (on/off)
is installed on top of ground!
hole in table for counterpressure (stroke 200 mm)
Rexroth hydraulic unit 300 bar operating pressure
Tipo/Modelo: 1000 ton 4 column press
Numéro stock: M.06 13995
Categoría principal: [M] Prensas hidráulicas
Subcategoría: [M.06] Prensas de 4 columnas de una carrera
Marca: HL

» Solicitar un presupuesto personalizado

Numéro stock: M.06 13995

Ver video de la maquinaria

Descargar todas las imágenes en ZIP
