Bandsagemaschinen Meba Eco-line 320 DGA automatic
Technische Informationen
- Ausladung500 mm
- Max werkstückhöhe325 mm
- Geschwindigkeit des bandsaege18 > 115 m/min
- Bandsaege-länge4400 x 34 x 1.1 mm
- Länge L -- R2680 mm
- Tieffe V -- H2350 mm
- Höhe 1350 mm
- Gewicht1800 kg
Zusätzliche Informationen
- Full automatic bandsaw with bundle clamp and autofeed
CNC controlled angle positioning
workpiece width in bundle clamping: 0-300 mm
workpiece height in bundle clamping: 5-300 mm
single material feed length: 0-600 mm
repeated material feed length: 0-9999 mm
maximum cutting capacity (90°, round): 325 mm
maximum cutting capacity (90°, rectangle): 500 x 300 mm
right mitre cut (45°, round): 300 mm
right mitre cut (45°, rectangle): 300 x 300 mm
right mitre cut (30°, round): 200 mm
right mitre cut (30°, rectangle): 200 x 200 mm
left mitre cut (45°, round): 300 mm
left mitre cut (45°, rectangle): 300 x 300 mm
- Typ/Modell: 320 DGA automatic
- Stocknummer: L.03 15939
- Hauptkategorie: [L] Sagemaschinen, Feilmaschinen & Abstechmaschinen
- Unterkategorie: [L.03] Bandsagemaschinen
- Markenname: Meba Eco-line
Stocknummer: L.03 15939
