Krawędziowe prasy hydrauliczne Amada HFP NT 400 ton x 4100 mm CNC

Name: Amada HFP NT 400 ton x 4100 mm CNC
Brand: Amada
SKU: O.01 16701

Produkt dodany do ulubionych

» Poprosić o indywidualną wycenę

Specyfikacja

Capacity x Max length400 ton x 4100 mm
BackgaugeCNC
ControlAMNC
Passage between uprights3230 mm
Max stroke350 mm
Max distance between table -- ram620 mm
Depth of throat420 mm
Table width250 mm
Locking speed75 mm/sec
Working speed10 mm/sec
Returning speed100 mm/sec
Electric motor (power)38,5 kW
Length 5490 mm
Depth2150 mm
Height3415 mm
Weight24,5 ton
Pojemność400 ton
Długość gięcia4100 mm

Dodatkowe informacje

7 osi: Y1 / Y2 / X1 / X2 / R / Z1 / Z2
Typ/Model: HFP NT 400 ton x 4100 mm CNC
Stocknumber: O.01 16701
Kategoria główna: [O] Giętarki, Prostownice, Wycinarki, Maszyny do cięcia laserowego, Maszyny do cięcia gazowego i Linie walcujące
Sub kategorii: [O.01] Krawędziowe prasy hydrauliczne
Marka: Amada

» Poprosić o indywidualną wycenę

Stocknumber: O.01 16701
