Microcut TC-2100 - X: 2100 - Y: 610 - Z: 610 mm CNC

Microcut TC-2100 X: 2100 - Y: 610 - Z: 610 mm CNC

Produkt dodany do ulubionych

Specyfikacja

Table longitudinal travel (X-axis)2100 mm
Cross travel head (Y-axis)610 mm
Height travel head (Z-axis)610 mm
Table dimensions2800 x 700 mm
Max weight on the table4 ton
Admission in spindle (ISO)ISO 40
Power on the spindle15/18,5 kW
Control (type)Fanuc oi-MC
Toolchangeryes
Number of toolholders48 positions
Number of rotations (from X to Y rpm)10 000 rpm
Power principal motor 49 kW
Weight23 ton

Dodatkowe informacje

TC = travelling column
Very similar to a Mazak VTC
Typ/Model: X: 2100 - Y: 610 - Z: 610 mm CNC
Stocknumber: D.01 10127
Kategoria główna: [D] Centra frezarskie
Sub kategorii: [D.01] Pionowe centra frezarskie
Marka: Microcut TC-2100

Stocknumber: D.01 10127

Sprzedany
