Toucheerpersen Erfurt PYXTu 50/4000

Teknik Bilgiler

Capacity20 - 50 Ton
Drawningspeed100 mm/sec
Returningspeed100 mm/sec
Passage between uprights4000 mm
Distance between table -- ram1700 mm
Table area4000 x 2200 mm
Dimensions of the base plate4000 x 2200 mm
Punch holder dia3600 x 1400 mm
Max counterpression in ram (max cap)50 ton
Adjustable stroke / counter-pression300 mm
Motor power80 kW
Length L -- R5000 mm
Depth Fw -- Bw2500 mm
HeightTot. 8000 mm
Weight58 ton

Ek bilgi

In ground :1700 mm
Tip/Model: PYXTu 50/4000
Stok numarası: M.16 7230
Kategori: [M] Hidrolik basınç
Alt kategori: [M.16] Toucheerpersen
Marka: Erfurt

Stok numarası: M.16 7230

Satılan
Satılan
Satılan
Satılan

ZIP formatındaki tüm fotoğrafları indirin
