Hydraulische Abkantpressen Safan E-brake 40 ton x 1600 mm CNC

Der Produkt ist zu Ihren Favoriten hinzugefügt

Technische Informationen

Kapazität x Max arbeitslänge40 ton x 1600 mm
Hinten anschlag:Manu(1)-Elektr-(2)CNC(3)CNC
SteuerungTS1
Durchgang zwischen Ständer1600 mm
Max Stossel290 mm
Abstand zwichen Tisch -- Stössel590 mm
SchlieBschnelligkeit180 mm/sec
Arbeitsschnelligkeit10 mm/sec
Zurücklaufschnelligkeit180 mm/sec
Elektromotor (kraft)11 kW
Länge L -- R2700 mm
Tieffe F -- H2000 mm
Höhe2800 mm
Gewicht4,1 ton

Zusätzliche Informationen

6 axes: Y / X / X' / R / Z1 / Z2
4 backgauge fingers
Wila hydraulic clamping
Typ/Modell: E-brake 40 ton x 1600 mm CNC
Stocknummer: O.01 13104
Hauptkategorie: [O] Abkantpressen, Walzmaschinen, Richtmaschinen, Lasermaschinen und Brennschneidmaschinen, Stanzmaschinen & Profilierungsanlagen
Unterkategorie: [O.01] Hydraulische Abkantpressen
Markenname: Safan

Stocknummer: O.01 13104

Verkauft
