Tornos CNC Victor TNS 5

Información téchnico

Volteo sobre bancada700 mm
Volteo sobre carro transversal460 mm
Distancia entre centros1200 mm
Máximo eje longitudinal (eje-Z)1070 mm
Máximo eje transversal (eje-X)130 + 340 mm
Cono de husillo A2-8
Diámetro agujero husillo77 mm
Potencia eje 22 kW
Rango velocidades 30-2500 rpm
ControlCNC
Current needed380 V
Peso8000 kg
ACCESORIES*
Chuck o Cabezal giratorio (3/4) -- Diametro310 mm
Hidráulico yes
Cantidad de Herramientas12 pos

Información adicional

Heavy duty CNC lathes -- Rapidfeed X 5 m/min - XZ 10 m/min -- Spindlebearing dia 130 mm -- Spindle inside taper MT 7 --Bedwidth 725 mm -- Standart cuttingtoolsize 320 mm -- Hole trough powerchucktube 65 mm -- Tailstickquilldia 110 mm -- Quillstroke 100 mm -- Quill taper (built-in type) MT 4
Tipo/Modelo: TNS 5
Numéro stock: A.07 2589 *05
Categoría principal: [A] Tornos
Subcategoría: [A.07] Tornos CNC
Marca: Victor

Numéro stock: A.07 2589 *05
