Stanko Ø 2500 mm

Product added to your favorites

» Request a personalised quote

Technical information

Chuck dia.2250 mm
Max turningdia -- passage2500 mm
Power on the spindle40 kW
Max hight of workpiece Z-axis1600 mm
Number of speeds1 > 80 rpm
Long 5065 mm
Wide5340 mm
Height4910 mm
Weight35,5 ton

Additional info

Type: Stanko 1525
max workpiece height: 1600 mm

Vertical caliper
max horizontal travel: 1390 mm
max vertical travel: 1200 mm

Crossbar
max travel: 1240 mm
Type/Model: Ø 2500 mm
Stocknumber: A.12 12738
Main category: [A] Lathes
Sub category: [A.12] Vertical turning machines conventional & CNC
Brand: Stanko
