Universal Milling machines & CNC Jafo FWR 40 J

Technical information

Max longitudinal travel X-axe1000 mm
Max cross-travel Y-axe350 mm
Max travel Z-axe500 mm
Max height workpiece750 mm
Power on spindle 7,3 pk
Boring head (2 x90°)90° -- 0° -- 90°
Max quill travel Z'150 mm
Admission in boring head (ISO)ISO 50
Spindlespeeds1600 rpm
Table size1500 x 400 mm
Table turning angle 45 °
ControlHand + Mechan.
Digital screenWizard 3
Power needed3x380V
Length2200 mm
Depth 2600 mm
Height2100 mm
Weight3600 kg
ACCESSORIES & TOOLING*
Coolant pump*

Additional info

Type/Model: FWR 40 J
Stocknumber: B.01 0022 *03
Main category: [B] Milling machines
Sub category: [B.01] Universal Milling machines & CNC
Brand: Jafo

Stocknumber: B.01 0022 *03

Sold
Sold
