Hartford VMC1230A X: 1230 - Y: 610 - Z: 610mm

Product added to your favorites

» Request a personalised quote

Technical information

X-axis1230 mm
Y-axis610 mm
Z-axis610 mm
Table dimensions1270 x 630 mm
Max weight on the table1200 kg
Depth of throat (uprights-spindlecenter)610 mm
Admission in spindle (ISO)ISO 50
Power on the spindle15 kW / 20 hp
Control Fanuc
Number of axes3
Toolchangeryes
Number of toolholders20 tools
Number of rotations50 - 6000 rpm
Power principal motor 25 kVa
Length3800 mm
Depth2800 mm
Height2800 mm
Weight9700 kg

Additional info

Type/Model: VMC1230A X: 1230 - Y: 610 - Z: 610mm
Stocknumber: D.01 8147
Main category: [D] Machining centres
Sub category: [D.01] Vertical machining centers
Brand: Hartford

» Request a personalised quote

Stocknumber: D.01 8147

Hartford VMC1230A X: 1230 - Y: 610 - Z: 610mm
