CNC lathes Unisign Unicom 6000 Ø 2000 x 1330 mm CNC
Technical information
- Swing over bedØ 2000 mm
- Max longitudinal travel Z-axis1000 mm
- Max cross travel X-axis2150 mm
- Power on the spindle70 kW
- Number of speeds2 > 450 rpm (25.000 Nm)
- CommandSiemens 840D
- Length10 500 mm
- Width8500 mm
- Height5200 mm
- Weight+- 40 ton
- Toolchangeryes
- Number of tools141 positions
Additional info
Unicom 6000 large 5 axis mill-turn machining center
(vertical lathe with 5 axis milling capabilities)
Milling:
- 36 kW power on spindle
- Type: HSK100A
- 1 > 6000 rpm
- 720 Nm
- high pressure cooling through spindle 50 bar
- universal angle milling and drilling head (2x auto indexing 2.5°)
Turning:
- 70 kW power on table
- 2 > 450 rpm
- 25,000 Nm of torque
- max swing: dia 2000 mm
- max workpiece height: 1330 mm
Tool storage for turning & milling:
- Type: HSK100A
- 141 positions
Table:
- 3 tables: Ø 1250 mm / Ø 1600 mm / Ø 1800 mm
- auto (un)loading
Radio measurement sensor
Brankamp collision monitoring
Integrated measuring system on the slide
Chip conveyor
Vision system with camera and separate screen
- Type/Model: Unicom 6000 Ø 2000 x 1330 mm CNC
- Stocknumber: A.07 16384
- Main category: [A] Lathes
- Sub category: [A.07] CNC lathes
- Brand: Unisign
Stocknumber: A.07 16384
