Stock number: N.06 8073
https://www.aptint.com/en/used-second-hand-machinery/h-frame-excentric-presses/verson-630-ton_8073
1 / 4
Sold
| Capacity | 630 ton |
|---|---|
| Max adjustable stroke | fixed 600 mm |
| Passage between uprights | 3500 mm |
| Distance between table -- ram | 1700 mm |
| Dimension of the table | 3200 x 2000 mm |
| Course adjustment | 500 mm |
| Electric motor power | 130 kW |
| Length | 7180 mm |
| Depth | 4000 mm |
| Height | 5500 mm (above ground) |
| Weight | 170 ton |
Description
slide adjustment motor: 10 kW
slide bolster: 3450 x 2000 mm
Bolster height above floor: 630 mm
