Hydraulic pressbrakes Amada Promecam RG 100 ton x 3050 mm

Technical information

Capacity100 Ton x 3050 mm
Backgaugemanual
Passage between uprights2600 mm
Max stroke100 mm
Max distance between table -- ram300 mm
Depth of throat400 mm
Locking speed38 mm/sec
Working speed9 mm/sec
Returning speed70 mm/sec
Electric motor (power)10 hp
Length3050 mm
Depth1650 mm
Height2080 mm
Weight5500 kg

Additional info

Type/Model: 100 ton x 3050 mm
Stocknumber: O.01 7946
Main category: [O] Press brakes, Bending machines, Straightening machines, Punching machines, Laser cutting machines & Flamecutting machines and Roll forminglines
Sub category: [O.01] Hydraulic pressbrakes
Brand: Amada Promecam RG

Stocknumber: O.01 7946

Sold
