Hydraulic pressbrakes Haco PPH 40160

Technical information

Capacity160 T x 4100 mm
Backgaugeelectr.
Passage between uprights3600 mm
Max stroke120 mm
Max distance between table -- ram325 mm
Depth of throat250 mm
Table width180 mm
Locking speed70 mm/s
Working speed7 mm/s
Returning speed63 mm/s
Length4270 mm
Depth1500 mm
Height2470 mm
Weight9500 kg
Bedknife+
Multi V-shaped clamp+

Additional info

Electrical depth adjustment.
Type/Model: PPH 40160
Stocknumber: O.01 3192 *07
Main category: [O] Press brakes, Bending machines, Straightening machines, Punching machines, Laser cutting machines & Flamecutting machines and Roll forminglines
Sub category: [O.01] Hydraulic pressbrakes
Brand: Haco

Stocknumber: O.01 3192 *07
