Plate rolls Fasti Schröder Reflector Slip Bending Roll CNC

Name: Fasti Schröder Reflector Slip Bending Roll CNC
Brand: Fasti Schröder
SKU: O.06 6666

Product added to your favorites

» Request a personalised quote

Technical information

Number of rolls4
Roll capacity cold1860 mm
Typehydraulic
Roll dia upside40 mm
Power needed3,39 kW
Weight1960 kg

Additional info

with CNC path control
Symmetric 3-roll slip bending without reflection marks
sheet thickness 180N/mm: 0.75 mm
length: 1850 mm
Type/Model: Reflector Slip Bending Roll CNC
Stocknumber: O.06 6666
Main category: [O] Press brakes, Bending machines, Straightening machines, Punching machines, Laser cutting machines & Flamecutting machines and Roll forminglines
Sub category: [O.06] Plate rolls
Brand: Fasti Schröder

» Request a personalised quote

Stocknumber: O.06 6666

Watch video of working machinery

Fasti Schröder Reflector Slip Bending Roll CNC

Download all pictures in ZIP
