Vertical turning machines conventional & CNC Dorries Ø 6500 x 4270 mm CNC

Name: Dorries Ø 6500 x 4270 mm CNC
Brand: Dorries
SKU: A.12 9712

Product added to your favorites

» Request a personalised quote

Technical information

Chuck dia.6000 mm
Max turningdia -- passage6500 mm
Power on the spindle200 HP
Max hight of workpiece Z-axis4270 mm
CommandSiemens/Heidenhain
Number of speeds1 > 40 rev/min
Long 20 500 mm
Wide8500 mm
Height6290 mm (above ground-level)
Weight220 ton

Additional info

Type: SD 600/6500
4-axis oriented ball screws
Hydrostatic table
Between columns: 6500 mm
Max height under crossbeam: 4270 mm
Vertical movement of the crossbeam: 2500 mm
Max weight on table: 160 tons
Torque of the table: 30,000 HP, 200 hp
Vertical movement of Y1 & Y2: 1750 mm
Two independent scissor lifts on each side of the lathe, with control unit
Type/Model: Ø 6500 x 4270 mm CNC
Stocknumber: A.12 9712
Main category: [A] Lathes
Sub category: [A.12] Vertical turning machines conventional & CNC
Brand: Dorries
